Main Advantages
- The guide wheel and load wheel of same diameter controls gyroscopic couple, which controls the vibration of movement through vertical & horizontal bends.
- It is absolutely a proven system to absorb any type of vibration or shock.
- The Trolleys and Links Axle are mainly made of alloy steel of EN-8 EDD qualities of C.R.C.A. sheets.
- The wheels are made of especially high quality high carbon and manganese steel balls.
Equipment Specifications:
Drive
The Overhead Conveyor system moves by caterpillar or sprocket type drive unit. There is a 1 HP or 2 HP TEFC motor that transmits the motion to speed gearboxes through ‘V’ Belts. The speed can also be regulated as per the necessity using other variable-speed-motors.
The output shaft of the speed Gearbox is fitted with a shear pin sprocket. This output shaft transmits motion to dog-chain or sprocket and directly engages two sets of trolleys at a time. It permits a relative motion between trolleys distributing drive power equally and automatically to monorail ensuring continuous movement of the system.
 |
|
Mono–O–Veyor system is provided with bi-planner type three, four and five wheel chain & trolleys having 6”, 9”, 12”, 9” and 15” pitch. Working tension (ALLOWABLE PULL) of the chain is 350 kg and the breaking load is 3500kg.
Service
We have a team of experienced staff to provide post-sale service to make the existing conveyor running perfectly. In addition, we also provide all the necessary spares made of high-grade steel. We provide total services job on annual basis that includes overhauling motor and gearbox.
